Tubular HEATERS | RHK series - Straight version

Ø 8,5 mm | Ø 12 mm | Ø 16 mm

Straight, annealed for bending, to DIN 44874/44875 and VDE 0720/0721.

straight length mm	Cat. No. Ø 8,5 mm	Cat. No. Ø 12 mm	Cat. No. Ø 16 mm
400	85110400	12110400	16110400
600	85110600	12110600	16110600
800	85110800	12110800	16110800
1000	85111000	12111000	16111000
1200	85111200	12111200	16111200
1400	85111400	12111400	16111400
1600	85111600	12111600	16111600
1800	85111800	12111800	16111800
2000	85112000	12112000	16112000
2200	85112200	12112200	16112200
2400	85112400	12112400	16112400
2600	85112600	12112600	16112600
2800	85112800	12112800	16112800
3000	85113000	12113000	16113000
3200	85113200	12113200	16113200
3400	85113200	12113400	16113400
3600	85113600	12113600	16113600
3800	85113800	12113800	16113800
4000	85114000	12114000	16114000
4250	85114250	12114250	16114250
4500	85114500	12114500	16114500
4750	85114750	12114750	16114750
5000	85115000	12115000	16115000
5250	85115250	12115250	16115250
5500	85115500	12115500	16115500

Available on request: other lengths and heating capacities, unheated zones, other voltages and materials.
